靜電式油煙凈化器是目前國內主流的油煙凈化器設備。其凈化工作原理以及工作優點都是很引人注意的，下面
濟南油煙凈化器廠家為您講解講解吧。
Electrostatic oil fume purifier is the mainstream equipment of oil fume purifier in China at present. The working principle and advantages of its purification are very attractive. Let's explain it to you from Jinan oil fume purifier manufacturer.
靜電油煙凈化器凈化流程原理
Purification process principle of electrostatic fume purifier
煙氣分離：
Flue gas separation:
電場在外加高壓的作用下，負極的金屬絲表面或附近放出電子迅速向正極運動，與氣體分子碰撞并離子化。油煙廢氣通過這個高壓電場時，油煙粒子在極短的時間內因碰撞俘獲氣體離子而導致荷電，受電場力作用向正極集塵板運動，從而達到分離效果。
Under the action of external high voltage, electrons released from or near the surface of the metal wire of the negative electrode quickly move to the positive electrode, collide with gas molecules and ionize. When the oil fume exhaust gas passes through this high-voltage electric field, the oil fume particles will be charged due to the gas ions captured by the collision in a very short time, and move toward the positive electrode dust collecting plate under the action of the electric field force, so as to achieve the separation effect.
這種設備的投資少、占地小、無二次污染、運行費用低。由于易于捕捉粒徑較小的粉塵，凈化效率高，可達85~95%。它的凈化優點是：分離力是靜電力，直接作用在粒子上，而不是作用在氣流上，因此具有能耗低，阻力小的特點。
This kind of equipment has the advantages of less investment, small land occupation, no secondary pollution and low operation cost. Because it is easy to capture dust with small particle size, the purification efficiency is high, up to 85~95%. Its purification advantage is that the separation force is electrostatic force, which directly acts on particles rather than on air flow. Therefore, it has the characteristics of low energy consumption and low resistance.
靜電粒子荷電：
Electrostatic particle charge:
含有粉塵顆粒的氣體，在接有高壓直流電源的陰極線(又稱電暈極)和接地的陽極板之間所形成的高壓電場通過時，由于陰極發生電暈放電、氣體被電離，此時，帶負電的氣體離子，在電場力的作用下，向陽板運動，在運動中與粉塵顆粒相碰，則使塵粒荷以負電，荷電后的塵粒在電場力的作用下，亦向陽極運動，到達陽極后，放出所帶的電子，塵粒則沉積于陽極板上，而得到凈化的氣體排出防塵器外。
When the gas containing dust particles passes through the high-voltage electric field formed between the cathode line (also known as corona electrode) connected with the high-voltage DC power supply and the grounded anode plate, the corona discharge occurs at the cathode and the gas is ionized. At this time, the negatively charged gas ions move toward the anode plate under the action of the electric field force, and collide with the dust particles during the movement, so that the dust particles are negatively charged. The charged dust particles are charged by the electric field force, It also moves towards the anode. After reaching the anode, the electrons carried are released, and the dust particles are deposited on the anode plate, and the purified gas is discharged out of the duster.
靜電油煙凈化器的技術優點：
Technical advantages of electrostatic oil fume purifier:
1.處理風量大，壓損小?？梢栽诟邼袂闆r下運行。
1. The treatment air volume is large and the pressure loss is small. It can operate under high humidity.
2.一次通過去除率可以滿足凈化要求。
2. The removal rate of one pass can meet the purification requirements.
3.有效去除的粒子直徑范圍大。
3. The diameter range of particles effectively removed is large.
This is the principle and technical advantages of the purification process of electrostatic oil fume purifier. If you are interested in it, please come to our website http://m.shyrzs.com Consult and understand.
